Product Catalog

Complete range of microwave and millimeter wave chips. Click on categories to view detailed specifications.

Model Frequency (GHz) Gain (dB) Noise Figure (dB) P1dB (dBm) Vdd (V) Id (mA) Die Size (mm)
EC10217C-106ADC-631≤1.6-5250.52×0.52×0.08
EC10440C-00200.2-20241.5-5401.32×1.10×0.07
EC10308C-05270.5-2.723<1-5602.00×2.10×0.07
EC1065C-812A8-12171.8185952.02×1.05×0.07
EC10162C-8128-1220.51.3165552.00×1.20×0.07
EC10424C-8128-12250.6125301.20×1.20×0.07
EC10260C-5185-18201.4115601.80×1.20×0.07
EC10326C-6186-18261.3135602.25×1.15×0.07
EC10175C-121912-19261.535152.40×0.95×0.07
EC10239C-141814-18281.3105552.25×1.05×0.07
EC10166C-182518-25251.8-15102.15×0.90×0.07
EC10264C-324032-40212.345151.80×0.80×0.07

100+ LNA models available. Contact us for complete datasheet.

ModelFrequency (GHz)Psat (dBm)Gain (dB)PAE (%)Vdd (V)Idq (mA)Die Size (mm)
EC11258C-1924P21.9-2.433 dBm285085002.30×1.65×0.10
EC11286C-2061.9-6.130 dBm293083603.10×2.10×0.10
EC11570C-206P12-631 dBm293583503.10×2.50×0.07
EC11466C-2122-1223 dBm222051604.30×2.00×0.07
EC11753C-2182-1825.5 dBm253851003.50×1.50×0.07
EC1187C-5065-632.5 dBm31-86002.38×1.60×0.10
EC11165C-5065-639 dBm2640820003.60×3.15×0.10
EC11242C-506P125-640.8 dBm2340825004.50×4.20×0.10
EC11256C-506P165-642 dBm24388.538004.35×4.08×0.10
EC11201C-141814-1831 dBm193086003.45×2.65×0.10
EC11160C-141814-1834 dBm193086603.65×1.70×0.10
EC11310C-2431P424-3136 dBm3522625004.29×4.50×0.08

50+ GaAs PA models available. Contact us for complete datasheet.

ModelFrequency (GHz)Psat (dBm)Gain (dB)PAE (%)Vdd (V)ConditionDie Size (mm)
EC116650C-1116P71.1-1.638.5 dBm / 7W25.55728CW1.90×1.80×0.08
EC116483C-1215P251.2-1.544 dBm / 25W285028Pulse2.64×2.34×0.08
EC116744C-1428P61.4-2.839 dBm / 8W314828CW4.00×2.23×0.10
EC116649C-1621P81.6-2.139 dBm / 8W295828CW1.76×1.60×0.08
EC116243C-2335P182.3-3.542.6 dBm / 18W32.65028Pulse2.87×2.25×0.10
EC116819C-2735P152.7-3.542 dBm / 15W226036CW3.43×2.35×0.08
EC116158C-2735P202.7-3.544 dBm / 20W244836Pulse3.55×2.90×0.10
EC11684C-2735P30A2.7-3.545 dBm / 30W255728Pulse2.9×3.44×0.10
EC116480C-2735P502.7-3.547 dBm / 50W235528CW3.40×4.60×0.08
EC116736C-3540P403.5-4.046 dBm / 40W265828Pulse3.80×4.50×0.08
EC116384C-506P805-649 dBm / 80W264728Pulse3.50×5.55×0.08
EC116715C-708P1007-850.3 dBm / 100W215130Pulse4.00×5.32×0.10
EC116276C-812P88-1239 dBm / 8W203828Pulse2.50×1.60×0.08
EC116690C-812P168-1242 dBm / 16W225028Pulse2.00×2.50×0.08
EC116358C-812P608-1248 dBm / 60W224028Pulse4.00×5.30×0.80
EC116563C-8711P908.5-1149.8 dBm / 90W24.85028Pulse4.00×6.00×0.08
EC116238C-1315P8012.5-1549 dBm / 80W193028Pulse4.40×5.30×0.08
EC11691C-1416P5014-1647 dBm / 50W213032Pulse3.50×5.00×0.08
EC116824C-1418P6014-1848 dBm / 60W244028Pulse3.30×5.00×0.10
EC116807C-1822P2518-2244 dBm / 25W244428CW2.75×2.85×0.05
EC116519C-1940P1019-4039 dBm / 10W141424CW2.63×3.06×0.08
EC116223C-3236P2032-3643 dBm / 20W142522Pulse5.38×4.58×0.10
EC116309C-5763P357-6335 dBm / 3W151518Pulse4.84×2.75×0.05
EC116372C-9296P492-9636.5 dBm / 4W13.51018Pulse4.33×4.60×0.05

100+ GaN PA models available. Output power from 1W to 200W. Contact us for complete datasheet.

ModelFrequency (GHz)Psat (dBm)Gain (dB)PAE (%)Vdd (V)ConditionDie Size (mm)
EC116181C-103P100.03-340 dBm / 10W114628CW2.60×1.40×0.08
EC11687C-0320P100.35-2.040 dBm / 10W154028CW3.40×1.70×0.08
EC116527C-206P282-645 dBm / 28W214228CW3.85×4.25×0.10
EC116850C-208P402-846 dBm / 40W183028CW5.74×5.04×0.08
EC11688C-218P102-1840 dBm / 10W152028CW5.00×3.50×0.08
EC116783C-218P152-1842 dBm / 15W232028CW4.10×4.96×0.08
EC116528C-618P406-1846 dBm / 40W182528Pulse4.91×5.30×0.08
EC116737C-618P506-1847 dBm / 50W202828Pulse4.45×5.25×0.01
EC116267C-1840P1018-4040 dBm / 10W141424Pulse2.48×3.06×0.08
EC116787C-2640P1826-4042.5 dBm / 18W182028Pulse2.80×2.85×0.05

30+ broadband PA models available. Ultra-wideband coverage from MHz to 40GHz.

ModelFrequency (GHz)Psat (dBm)Gain (dB)PAE (%)IM3 (dBc)Vdd (V)Die Size (mm)
EC116448C-3560P43.5-6.036 dBm / 4W2535-28@28dBm281.79×1.94×0.08
EC11690C-2128P10A2.1-2.840 dBm / 10W26.540-35@33dBm282.35×2.70×0.08
EC116379C-2735P402.7-3.546 dBm / 40W2357-30@39dBm284.35×2.45×0.08
EC116142C-3436P403.4-3.647 dBm / 40W2840-28@40dBm284.40×3.40×0.08
EC116752C-405P404-546 dBm / 40W2450-30@40dBm283.50×3.40×0.08
EC116129C-1315P3512.5-15.345.5 dBm / 35W2033-30@40dBm285.00×6.65×0.08
EC116140C-2731P1027-3140 dBm / 10W1824-31@31dBm203.60×3.08×0.08
EC116823C-2731P2827-3144.5 dBm / 28W2030-30@40dBm223.40×6.00×0.05

20+ linear PA models available. Excellent linearity for communication systems.

ModelFrequency (GHz)Psat (dBm)Gain (dB)PAE (%)Vdd (V)ConditionDie Size (mm)
EC116790C-0820P80.8-2.039.5 dBm / 8W274828CW3.60×3.20×0.10
EC116512C-218P62-1838 dBm / 6W142028CW5.00×4.00×0.08
EC116776C-510P305-1045 dBm / 30W234228Pulse4.40×4.90×0.08
EC116727C-618P66-1838 dBm / 6W182028Pulse3.50×2.50×0.08
EC116836C-818P128-1841 dBm / 12W193528Pulse3.10×2.60×0.08
EC116701C-1218P1312-1841.5 dBm / 13W20.53628Pulse4.00×1.60×0.08
EC116772C-1218P2012-1843 dBm / 20W193028Pulse4.00×2.80×0.08
EC116457C-323832-3829 dBm192024Pulse3.30×1.70×0.08

20+ PA+Switch integrated chips available. T/R switch integrated for T/R module applications.

ModelFrequency (GHz)Psat (dBm)Gain (dB)PAE (%)Vdd (V)ConditionDie Size (mm)
EC116617C-03200.3-2.044 dBm / 25W234548VCW2.80×1.45×0.08
EC116641C-506P1605-652 dBm / 160W225048VPulse4.50×5.30×0.08
EC116491C-810P2008.0-10.553 dBm / 200W234548VPulse4.10×5.50×0.08
EC116404C-812P1508-1252 dBm / 150W214048VPulse3.75×5.30×0.08
EC116407C-1517P10015-1750 dBm / 100W203548VPulse3.40×4.50×0.08
EC116791C-1617P8016-1749 dBm / 80W213548VPulse6.00×3.60×0.08

High voltage GaN PAs up to 48V operation. Ultra-high power density for radar and EW applications.

ModelFrequency (GHz)BitsInsertion Loss (dB)RMS Phase ErrorControl (V)Amplitude VariationDie Size (mm)
EC12187C-0820PD0.8-2.06-bit123°+5/0±0.5 dB5.60×3.20×0.07
EC1220C-1121-1.26-bit4.81°0/-5±0.15 dB6.20×2.00×0.10
EC12172C-2062-66-bit123°0/-5±0.5 dB5.00×3.00×0.07
EC1286C-8128-126-bit82.4°0/-5±0.4 dB3.50×1.70×0.07
EC12296C-1018PD10-186-bit134°+5/0±1 dB1.55×3.25×0.07
EC12160C-242924-296-bit102°0/-5±0.5 dB2.50×1.20×0.07
EC12163C-304030-406-bit84°0/-5±0.75 dB3.15×1.30×0.07
EC12198C-506 (GaN)5-66-bit62.5°0/-28±0.5 dB3.70×1.40×0.08
EC12197C-812 (GaN)8-126-bit10.52°0/-10±0.8 dB5.05×1.85×0.08

50+ digital phase shifter models available. 4/5/6/8-bit options with parallel/serial control.

ModelFrequency (GHz)BitsInsertion Loss (dB)Step (ps)Max Delay (ps)Control (V)Die Size (mm)
EC12171C-04200.35-26-bit122515750/-55.00×4.00×0.07
EC12115C-1060.5-68-bit≤18512750/-55.50×3.50×0.07
EC12126C-2182-186-bit≤22106300/-54.00×2.60×0.07
EC12164C-6186-186-bit10.51.3820/-52.50×2.00×0.07
EC12170C-101810-183-bit1462.5437.50/-53.50×3.00×0.07
EC12144C-1418PD14-186-bit100.97531+5/02.50×2.30×0.07
EC12260C-1722SD17-226-bit236378+5/03.00×3.60×0.07
EC12261C-1722SD17-227-bit336762+5/04.50×3.60×0.07

40+ digital delay line models available. True time delay for wideband phased array systems.

01

Limiters

RF power limiters for receiver protection, various power levels

02

Mixers

Up/down converters, mixers for frequency translation

03

Switches

SPDT, SP4T, SP8T RF switches with high isolation

04

Filters

LC filters, BPF, LPF, HPF for various bands

05

Attenuators

Digital step attenuators, analog VGA

06

Multi-function Chips

Integrated T/R chips, beamforming ICs

07

Power Transistors

GaN/GaAs/Si power transistors, pre-matched devices

08

Packaged Modules

Ceramic packaged circuits, SIP modules

09

3D Integrated Modules

Silicon-based 3D integrated micro-modules

10

Passive Components

Resistors, capacitors, couplers, power dividers

Contact us for complete product catalog and datasheets.
We can also provide custom design services for specific requirements.
